Emergency announcement recordings or various warning and information announcements can be transmitted automatically or manually in areas where people are densely populated such as factories, cultural centers, holiday resorts, headquarters buildings, plazas, educational facilities, hypermarkets, shopping malls, airports. devices are used. The message stored in the emergency announcement module with the contact from the fire switchboard can be given to the entire public address system when desired. It is through this recording that people are informed about what they should do in case of a fire. Informing and warning messages can be given to people from any location by means of a mushroom button.



1. 10 Digital Recorder 10 Channel "ON/OFF" switch is turned on. It is seen that the light of the power switch is on.



2. Mp3 format announcements or melodies previously recorded are uploaded to the device via a USB cable.



3. To the terminals on the back of the device, if desired, authorized persons can make recorded announcements by means of the contact from the fire alarm switchboard or mushroom buttons.



4. The contact from the fire alarm switchboard is entered into the terminal, so that the emergency announcement recorded in the system is given to the sound system when a call comes from the fire alarm switchboard.



 5. Announcement volume is adjusted.

When the trigger input is short-circuited, it starts to record or play an announcement.



The alarm stops automatically when the fire contact is closed. Controlled manually.

MIC Alarm shutdown recording with priority function.



* Power Supply; 220V-240V, 50 Hz

*Remote Input; Short circuit signal

*Output Alarm Signal; 1V / 0 dB, 10k

* Recording, Memory; 8Mb, MP-3 format

* Recording Level - 20dBV (line in)

*Size; 483x88x200mm (Width, height, or output register)

* Gross Weight; 3.50 kg

* Net: Weight; 3.00 kg
