The CS-06 ceiling speaker provides excellent sound output. It is made of strong material for long-lasting durability. CS-06 ceiling speaker is compatible with various electronic devices.



CS-06 is a ceiling speaker with a built-in 70v/100v transformer. The 70v/100v transformer technique reduces line losses over longer distances and allows multiple speakers to be easily connected in parallel.



CS-06 speaker drivers are designed for a wide frequency response of 90-16kHz, 5W power connections give satisfactory results for applications. Easy and safe installation with spring mounting clip.

Industrial and commercial applications such as hotels, offices, schools and factories where background music and announcements are needed. ideal for applications.

Rated / Max Power 5W/10W

Internal Speaker 160mm

SPL(1W/1M) 92dB ± 3dB

Max. SPL 100dB

Frequency Response 90 – 16,000 Hz

Volts 70V/100V

Dimensions (Outer Dia/Hole Diameter) 199mm / 165mm

Assembly Spring Clip

Termination Recessed screw connection
